Truck-mounted road sweepers
4×2 Road Sweeper Truck
A Dongfeng 4×2 road sweeper truck with a 7,000L hopper and 9,000L water tank for evaluating water-assisted municipal cleaning.
- Nominal capacity
- 7,000 L
- Drive layout
- 4×2
- Reference model
- CLW5181TXS6SL
THE APPLICATION
4×2 Road Sweeper Truck
An 18,000 kg gross vehicle weight and 125 kW auxiliary engine characterize this Dongfeng reference. Evaluate the separate working-engine arrangement against the single-engine sweeper option. Discuss the water-assisted task and refill pattern alongside the hopper-emptying schedule.
CONFIGURE THE WORKING EQUIPMENT
Configuration
Fleet comparison
This configuration pairs 7,000L of nominal hopper storage with a 9,000L water tank. Compare it for cleaning assignments where water supply and collected debris require separate planning. The balance differs from the dry-and-wet model’s 11,000L dust compartment and 6,500L water tank.
Vehicle layout
The CLW5181TXS6SL reference is 8,000 × 2,500 × 3,100 mm, with a 5,100 mm wheelbase. Its 3.2 m reference sweeping width describes the working pass rather than the parked width. Compare the pass arrangement with parked vehicles and the section available to clean.
THE DATASHEETProduct specificationsExpand all groupsCollapse specifications
Dimensions and equipment describe the reference configuration. The final quotation identifies the supplied chassis, body and working equipment.
Model & dimensions
| Reference model | CLW5181TXS6SL |
|---|---|
| Vehicle manufacturer | Chengli (CLW) |
| Chassis brand | Dongfeng |
| Length × width × height | 8000 × 2500 × 3100 mm |
| Gross vehicle weight | 18,000 kg |
Chassis & powertrain
| Chassis brand | Dongfeng |
|---|---|
| Drive layout | 4×2 |
| Transmission | Manual |
| Wheelbase | 5,100 mm |
| Fuel | Diesel |
Body & capacity
| Waste hopper capacity | 7,000 L |
|---|---|
| Water tank capacity | 9,000 L |
| Body material | Stainless steel |
Working system
| Cleaning arrangement | Wet-type |
|---|---|
| Auxiliary engine | Cummins |
| Auxiliary engine power | 125 kW |
Working performance
| Maximum sweeping width | 3.2 m |
|---|
BEFORE YOUR ENQUIRY
Buyer questions
How do the hopper and water volumes compare with dry-and-wet?
This reference has a 7,000L hopper and 9,000L water tank. The dry-and-wet alternative has more nominal dust storage but less water, changing the emptying and refill comparison.
Is 3.2 m the parked vehicle width?
The 3.2 m figure is the reference sweeping width; the vehicle width is 2,500 mm. Use each figure for its own comparison of working passes and road access.
What is different from a single-engine sweeper?
This reference lists a 125 kW auxiliary working engine. Compare that power arrangement and its service planning with a truck using one engine for driving and cleaning.
